The Steps Introduction To Produce The Chain Link Wire Mesh

Dec. 29, 2018

 The Steps IntroductionTo Produce The Chain Link Mesh

  • According to customer’s request to book the steel wire material. The available wire material it is galvanized wire, PVC coated wire,  Stainless steel wire.

  • Put the wire material on the wire roller, the wire goes into the automatic machine and start woven mesh.

  • The machine working principle: The spiral continues to rotate past the blade and winds its way through the previous spiral that is already part of the fence. When the spiral reaches the far end of the fence, the spiral is cut near the blade. Next, the spiral is pressed flat and the entire fence is moved up, ready for the next cycle. The end of every second spiral overlaps the end of every first spiral. The machine clamps both ends and gives them a few twists. This makes the links permanent.

  • After one roll finished then it can be Roll up and shrink roll diameter.

  • Rolls Package, as usual, the package for the chain link fence it is: tow side with plastic woven bags and then shrinks by a plastic film.
