Several reasons for the failure of stainless steel mesh belt chain conveyor

Oct. 27, 2022

The stainless steel mesh belt chain is the part that is prone to malfunction in the mesh belt conveyor. Under the action of traction, the mesh belt chain often has static and dynamic conflicts. The larger conflict force reduces the cross-section of the chain ring or the connecting ring of the mesh belt chain, the strength decreases, and even the chain breakage accident occurs. The double-sided mesh belt chain often causes the mesh belt to be inclined due to improper matching. The length difference of the mesh belt chain is too large, which can easily cause a chain to be subjected to large force and wear, and even cause the chain to dislocate or "jump teeth" on the sprocket.

The installation of the mesh belt should conform to the delineated direction, the distance should meet the requirements, and the bending deformation of the mesh belt should not exceed 5mm. There shall be no twist or twist in each unit or the whole mesh belt chain. The mesh belt, mesh belt chain and connecting ring are the frequent points of accidents. The nut should be tightened to the specified torque to make it a three-in-one rigid component. After the mesh belt conveyor is installed, the no-load chain ring should be run for 2 to 8 hours before it is officially put into operation. When the chain is extended again, it should be readjusted. After running for about 2 weeks, due to the load of the mesh belt conveyor, the chain links are further worn in, and you should also pay attention to check the tightness, so as to adjust in time to prevent the occurrence of chain breakage.

The influence of uneven and straight laying on the operation of the mesh belt conveyor: The premise of the working environment is to adapt to the characteristics of the stainless steel mesh belt chain conveyor. 20 to 60. The stainless steel mesh belt chain conveyor should be flat, including two aspects: horizontal and vertical. In addition, some material residues run to the bottom of the chute to increase the resistance, and it is also easy to cause chain breakage or damage to parts, and even burn out the motor. Therefore, the unevenness and non-straightness of the mesh belt conveyor are extremely harmful to the operation of the stainless steel mesh belt conveyor, resulting in complicated incidents. The greater the angle of the chute, the greater the traction force. If the zigzag break is close to the nose, the greater the traction force is added.
